Battery Amps

Anyone know if the below is correct for a homebuild li-ion. It seems a very high amp rating.

First, we find the average resistance per cell:

  • Average Cell IR: 42.7 mΩ / 5 cells = 8.54 mΩ per cell

​An internal resistance of just 8.54 mΩ per cell is excellent for a 5500mAh pack. Using this correct value, we get these performance figures:

  • True C Rating: ~78C
  • Max Continuous Amps: ~433 A
  • Max Continuous Power: ~8,015 Watts (8.0 kW)

Thanks

You better use the cell manufacturer specs - resistance likely varies quite a lot in use

The latest P50’s (standard 21700 size) are given as 50Ah with a 75A max discharge for example

1 Like

Purchased a 6s 6000mah lipo as it has a bit more grunt. The 2 x 5500mah 5s li-ion i made are doing around 18 mins each. The lipo 6s did 20 mins today with a bit left over.

I think a good tune will make it better and possibly 3000mah lighter battery for a bit more fun as 20mins felt like forever

2 Likes

What is the weight of your liion packs? Usually you can carry lot more Ah using Liion (2 of my 5000mAh 6S Liion weighs nearly the same as a single 6000mAh Lipo for example.

My 6S 6000 lipo weighs 650 and the 5s 5500 weighs 520

I did double up the 5s to a 11000mah but it was huge and lasted to long. I decided the feel of the drone was better with the 520g instead of 1040g load. Tbh i was shocked how easily it lifted 1040g

I think the liion are heavy due to using smaller cells but i was given 2 new drill batteries for free and thought what the hell ill strip them. It was more an experiment than a long term power solution.

I was going to buy some proper liion packs but couldn’t find many in the uk.
As you can tell im a bit of a tinkerer but i think that comes from years in I.T and Engineer. For me everyday is a school day and i love to drain people of information. :wink:

Cheers for all the advice
